HamKing DS-3000 Discone Multi Band Antenna
HamKing DS-3000 Discone Multi Band AntennaHamKing DS-3000 Discone Multi Band AntennaHamKing DS-3000 Discone Multi Band AntennaHamKing DS-3000 Discone Multi Band AntennaHamKing DS-3000 Discone Multi Band Antenna


HamKing DS-3000 Discone Multi Band Antenna


Ref:  32HK-DS-3000
Bar Code:  8718375101247
Brand:  HamKing

Weight:  690 g

Availability:



Product information

The HamKing DS-3000 is the perfect base antenna for use with a radio scanner. Not only receives the DS-3000 from 75 to 3000 MHz, it also is suitable for transmitting on the 144 MHz, 430 MHz, 900 MHz and 1296 MHz bands with a maximum power of 50 watts.

Specifications

Electrical Data:

  • Frequency band: Scanner/
  • Frequency: RX: 75-3000 MHz / TX: 144/430/900/1200 MHz
  • Gain: 2.15 dBi (144 MHz), 3 dBi (430/900/1200 MHz)
  • VSWR: <1.5 Power:50 watts
  • Impedance: 50Ω
  • Type:Discone
  • Radiation: Omnidirectional

Mechanical Data

  • Weight: 690 gram
  • Length: 154 cm
  • Connector: UHF female
  • Mast Ø:30 - 48 mm
  • Max wind resistance:40 m/sec (144 km/h)
